Demag AC 60

Mobile Crane

The Demag AC 60 is a compact, 60-ton capacity city crane with four axles, launched at Bauma 2001 in Munich. Known for its innovative design, it features an 8.20-meter compact carrier, which is shorter than many three-axle models, and an overall length of 9.88 meters due to a slight boom overhang. The crane boasts a 50-meter main boom and a 13-meter extension, achieving a maximum tip height of 63 meters. Equipped with advanced steering systems, it offers unparalleled maneuverability and the smallest turning radius in its class, making it highly effective in urban environments.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

The Demag AC 60 city crane emerged as a significant addition to the Terex lineup in 2001, offering a blend of compact design and robust lifting capabilities. It stands out with its class-leading 50-meter main boom, complemented by a 13-meter extension that allows it to reach a tip height of up to 63 meters—ideal for high-rise urban construction tasks.

Dimensions and Mobility: The AC 60’s compact design includes a total length of 9.88 meters with an 8.20-meter carrier, smaller than typical three-axle truck models. This compactness, coupled with an all-wheel steering system including crab control, ensures excellent mobility and ease of operation in tight city spaces.
Engine and Transmission: Powered by a DaimlerChrysler OM 457 LA engine, the crane delivers 295 kW (400 hp) and a torque of 1850 Nm, integrated with an electronically automated 16-speed gearshift system. This setup not only enhances on-site performance but also supports efficient road travel.
Operational Efficiency: The crane includes a fully hydraulic boom system capable of telescoping under load, which shortens setup times and increases operational flexibility. Its innovative Demag IC-1 crane control system with a color touchscreen display allows for precise handling and monitoring of crane operations.
Safety and Comfort: The operator’s cab is designed for maximum comfort and safety, featuring a sliding door, a large fold-out windscreen, and standard air conditioning. Safety features include an electronic safe load indicator, pressure-relief valves, and comprehensive lighting compliant with EC directives.

Overall, the Demag AC 60 combines advanced technological features and compact design to meet the needs of urban construction environments, offering a powerful yet maneuverable crane solution for city-based projects.
