Hitachi-Sumitomo ATX1000(6)

The Hitachi Sumitomo ATX1000 is a high-performance all terrain crane designed for versatile and demanding lifting tasks, blending robust lifting capabilities with compact transport dimensions. With a maximum lifting capacity of 100 tonnes, this crane is equipped with a 6-section fully hydraulic telescopic boom that extends from 11.1 meters to 52 meters. It can be further configured with a jib extension ranging from 10.1 meters to 17.7 meters, giving it a maximum lifting height of 69.5 meters and a maximum working radius of 56 meters.

One of the ATX1000’s key advantages lies in its compact body and strong lifting charts even with its compact frame, allowing it to operate effectively in urban or restricted sites. The crane is powered by a Mercedes-Benz OM470LA diesel engine delivering 330 kW (449 PS) and compliant with Euro IV (Stage IV) emission standards, combining high output with environmental responsibility. Its 5-axle all-wheel drive and steer system provides superior maneuverability and a minimum turning radius of just 10.5 meters.

The ATX1000 is fitted with two 5-tonne winches and features a lifting speed of up to 130 m/min with a 14 mm diameter wire rope. Slewing speed reaches up to 2.2 rpm, ensuring smooth, responsive operations. The crane is also equipped with a hydraulic suspension system for better on-road travel and job site performance. Safety and operational features include automatic moment limiters, swing angle sensors, and a large color display in the cab that gives operators intuitive access to lifting data and diagnostics.

Built with transport efficiency and high lifting performance in mind, the Hitachi Sumitomo ATX1000 meets the modern demands of infrastructure, civil engineering, and general construction sectors.
