Zoomlion QAY200V733

Mobile Crane

The Zoomlion QAY200V733 is an advanced all-terrain crane with a 200-ton lifting capacity, designed to meet the needs of modern construction with its dynamic and technologically advanced features. This crane features a 5-axle chassis, full range slewing capabilities, and a sophisticated electro-hydraulic proportional control system. Equipped with a telescopic boom that extends from 13.4 to 72 meters and additional jib options, the QAY200V733 excels in versatility and lifting performance, suitable for various industries including construction, mining, and oil fields.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

Performance and Capabilities

Maximum Lifting Capacity: 200,000 kg, providing substantial load handling for heavy-duty tasks.
Boom and Jib Configurations: The main boom has a maximum length of 72 meters, with a jib that can extend up to 95 meters (103 meters with extensions), enabling high-reach and extensive lifting operations.
Load Management: Features a maximum load moment of 6664 kN·m at an 8-meter radius, ensuring stability and safety during high-capacity lifts.

Advanced Control and Operation Systems

Control Systems: Integrates state-of-the-art electro-hydraulic proportional controls with multiple function capabilities including “Spool up/Reel off main winch”, “Derrick”, “Slew”, and “Telescope” operations for enhanced precision and flexibility.
Safety Systems: Includes comprehensive safety features such as relief valves, load moment limiter, and night operation lighting systems, ensuring operation safety under various conditions.

Structural and Mobility Features

Chassis and Mobility: The 5-axle chassis manufactured by Zoomlion provides excellent mobility on varied terrains. The crane can reach a maximum driving speed of 75 km/h and is equipped with advanced steering capabilities allowing up to 360 degrees rotation.
Dimensions and Transport: When assembled for transport, the crane has dimensions of 16000 mm in length, 3000 mm in width, and 4000 mm in height, with a total driving weight of 12000 kg, making it relatively easy to maneuver and transport.

Engine Specifications

Engine Power: Equipped with a 360 kW engine at 1800 rpm and a maximum torque of 2200 N·m at 1300 rpm, it aligns with environmental standards, adhering to National stage III emission regulations.
Efficiency: The fuel consumption rate stands at 78 liters per hundred kilometers, optimized for both performance and environmental conservation.

Overall, the Zoomlion QAY200V733 is designed not only for performance but also for operational efficiency and safety, making it a highly capable and reliable choice for complex and demanding lifting tasks across various sectors.
