Zoomlion ZTC1000V753

The Zoomlion ZTC1000V753 is a high-performance 100-ton truck-mounted hydraulic crane, engineered to deliver superior lifting capacity, efficient mobility, and intelligent control. The crane features a seven-section U-shaped telescopic boom, constructed from high-strength steel, extending from 13.2 meters to 70 meters, ensuring excellent load-bearing capacity, structural rigidity, and reduced deflection. Additionally, it includes a two-section lattice jib (10.4m and 17.5m) with adjustable offsets of 0°, 15°, and 30°, and an optional 9.5m jib extension, allowing for a maximum lifting height of 97.8 meters. The maximum lifting moment of 3,611 kN·m ensures powerful lifting performance for a wide range of heavy-duty applications.

The ZTC1000V753 is powered by a WEICHAI WP12.375E50 diesel engine, delivering 276 kW of output and a maximum torque of 1,800 N·m, optimized for fuel efficiency and high-performance operation. The crane can reach a top speed of 80 km/h, with a gradeability of 40%, making it highly efficient for on-road and off-road transportation. The minimum turning diameter of 24 meters enhances maneuverability, while the ground clearance of 310 mm ensures smooth operation on rough terrains.

For lifting efficiency, the ZTC1000V753 is equipped with dual high-speed winches, delivering a main hoist rope speed of 130 m/min and an auxiliary hoist rope speed of 110 m/min, ensuring fast and precise load handling. The boom derricking time is 60 seconds, while boom telescoping takes 750 seconds, allowing for efficient setup and operation. The slewing system, featuring a speed range of 0 – 1.6 rpm, incorporates load-sensing technology, ensuring smooth rotation and precise load positioning.

The chassis is designed for stability and durability, featuring an H-type outrigger system, with a fully extended transversal width of 8.0 meters and a longitudinal extension of 6.94 meters, ensuring exceptional stability during lifting operations. The tail slewing radius of 4,760 mm further enhances load balance and operational safety.

Operator comfort and safety are key priorities in the ZTC1000V753. The spacious, ergonomically designed cab features climate control (AC and heater), an adjustable seat, and an intuitive control panel, ensuring a comfortable and user-friendly working environment. The crane is equipped with an advanced electro-hydraulic proportional control system, utilizing a load-sensing directional valve system, ensuring optimized energy efficiency, precise movement coordination, and reduced operational fatigue.

Safety features include a load moment indicator (LMI), relief valves, balance valves, and emergency stop functions, ensuring secure and stable operations. The crane meets modern emission and safety standards, ensuring compliance with global regulations.
