Zoomlion ZTC600R532

Hydraulic Truck Crane

The Zoomlion ZTC600R532 is a robust hydraulic truck crane featuring a 45-meter “U”-shaped boom segmented into five sections, providing a maximum lifting capacity of 10 metric tons at full extension. Designed for heavy-duty tasks, this crane is mounted on a 42-ton rated chassis, capable of high-speed operations up to 85 km/h with a 5-ton counterweight. Its Weichai WP10.375 engine and Fast 10-speed gearbox ensure powerful, stable, and reliable performance across diverse environments.

Downloads

*Crane Specifications, Load Charts, and Crane Manuals are for reference only. Contact the crane manufacturer for manuals to operate the crane properly.

Related Models

Product Description

General Overview

The Zoomlion ZTC600R532 hydraulic truck crane excels in heavy lifting with its advanced design and engineering, making it suitable for a variety of demanding construction scenarios. The crane’s robust chassis and powerful drive system allow for efficient transport and operation even under challenging conditions.

Capacity and Boom Details

This crane features a 45-meter telescopic boom, composed of five “U”-shaped sections, optimized for strength and flexibility. The boom’s design ensures maximum lifting capacity of 10 tons when fully extended. The crane also supports a fixed counterweight of up to 11 tons, enhancing its stability and lifting power.

Drive and Performance

Equipped with a Weichai WP10.375 engine coupled with a Fast 10-speed gearbox, the ZTC600R532 offers a reliable and strong performance. The classic transmission chain of the vehicle ensures smooth operation, essential for the precision required in heavy lifting tasks.

Mobility and Outriggers

The ZTC600R532 is built on a heavy-duty 42-ton chassis that supports high mobility and speed, enabling the crane to travel at up to 85 km/h with a 5-ton counterweight. It features H-type movable outriggers with a maximum climbing grade of 47%, significantly improving its operational versatility and environmental adaptability.

Safety and Environmental Compliance

Zoomlion has equipped the ZTC600R532 with various safety devices, including wire rope over-discharge protection and outrigger over-pressure protection, which safeguard against operational errors and enhance both product and personal safety. Furthermore, the crane meets the European Stage III standards for exhaust emissions (ECE R24 and ECE R49), and its safety devices are CCC certified.

Fuel Efficiency

Despite its large size and heavy-duty capabilities, the ZTC600R532 maintains a relatively efficient fuel consumption rate of 43 liters per 100 kilometers, making it an economically viable option for extensive construction projects.

Applications

This crane is particularly effective in large-scale construction projects, infrastructure development, and other industrial applications where high capacity lifting is required. Its combination of extensive reach, powerful lifting capability, and advanced safety features make the Zoomlion ZTC600R532 a critical asset for challenging and diverse operational needs.
